Our 50W LED street light is sized for lower-mounting-height applications — residential streets, community pathways, parks, and small parking areas — where a 100W+ fixture would be oversized and inefficient. Up to 150 lm/W efficiency and IP65/IK08 protection keep maintenance low across a 50,000+ hour rated lifespan.
Balanced, uniform beam distribution reduces dark spots on narrow community roads
Die-cast aluminum housing with IP66 waterproof and IK08 impact resistance
MEAN WELL / PHILIPS driver options with 0–10V dimming or basic sensor control
Compact structure suited for lower pole heights and closer post spacing
Series A — MVS-SL050A (145 lm/W, 64 LEDs, 4.7kg, 90°×120° beam)
Best for municipal and secondary roads where energy efficiency is the priority.
Series B — MVS-SL050B (140 lm/W, 128 LEDs, 4.7kg, 80°×150° beam)
Uniform wide-beam coverage suited for parks, residential roads, and small industrial parks — a cost-effective balance for small-to-mid projects.
Series C — MVS-SL050C (150 lm/W, 112 LEDs, 5.3kg, 90°/120°/80°×150° beam options)
Multiple beam and driver configurations (Mean Well/Philips) for engineering clients with specific optical or brand requirements.
A customer in Malaysia selected 230 sets of MVS 50W LED street lights for the garden roads within a residential community. The roads were approximately 6 meters wide and required comfortable nighttime illumination without using unnecessarily high-wattage fixtures. The lighting layout used 6-meter poles installed along one side of the road. Pole spacing was adjusted between 18 and 24 meters according to the actual road alignment, landscaping, and site conditions. This flexible arrangement allowed the installation team to adapt the layoutto different sections of the community. Each 50W LED street light was configured with Philips LED chips, a Mean Well driver, and a 3000K color temperature. The warm-white output provided comfortable lighting for residents and pedestrians, while the compact 50W fixtures were straightforward to install along the community’s narrow garden roads.
| Project Configuration | |
|---|---|
| Product | 50W LED Street Light |
| Quantity | 230 sets |
| Project Location | Malaysia |
| Application | Residential garden road lighting |
| Road Width | 6 meters |
| Lighting Arrangement | Single-side installation |
| Pole Height | 6 meters |
| Pole Spacing | 18–24 meters, adjusted to site conditions |
| LED Chips | Philips |
| Driver | Mean Well |
| Color Temperature | 3000K |
| Model | Efficiency | Typical Pole Height | Recommended Applications | Best Suited For |
|---|---|---|---|---|
| 50W THIS MODEL | 140–150 lm/W | 6–8 m | Community roads, residential streets, pathways, parks and small parking areas | Lower-traffic roads and projects with lower mounting heights or moderate lighting requirements |
| 100W | Up to 150 lm/W | 8–12 m | Municipal roads, industrial parks, wider access roads and medium-sized parking areas | Projects requiring higher lumen output, wider road coverage and municipal-grade illumination |
| Parameter | MVS-SL050A | MVS-SL50B | MVS-SL050C |
|---|---|---|---|
| Model | MVS-SL050A | MVS-SL50B | MVS-SL050C |
| Power | 50W ~ 80W | 50W ~ 80W | 50W / 60W / 70W |
| Chip | NICHIA/LUMILEDS / CREE | NICHIA/LUMILEDS / CREE | NICHIA / LUMILEDS / CREE |
| Luminous Efficacy | 145 lm/W | 140 lm/W | 150 lm/W |
| CRI | ≥70 | ≥70 | ≥70 |
| Beam Angle | 90° × 120° | 80° × 150° | 90° / 120° / 80° × 150° |
| LED Driver | MEAN WELL | MEAN WELL | MEAN WELL / PHILIPS |
| Voltage (V) | 85–277V | 85–277V | 85–277V |
| LED QTY (pcs) | 64 pcs | 128 pcs | 112 pcs |
| Net Weight (kg) | 4.7 kg | 4.7 kg | 5.3kg |
Our 50W LED streetlights deliver uniform brightness and energy savings, perfect for residential roads, gardens, parks, and pathways. Built with internationally recognized chips and offering up to 145 lm/W, they combine performance with efficiency. With a 5-year warranty and reliable drivers, these streetlights are your ideal choice for community and landscape projects. Contact us today to customize your 50W streetlight solution.
TÜV-certified CE and CB. Factory operates under ISO 9001 quality management standards. Driver configurations comply with EMC and LVD testing.
A: Residential roads, gardens, parks, pathways, parking lots, and community areas — projects with lower mounting height and lower traffic volume than standard municipal roads.
A: If your installation height and road width match a residential or community-scale project, 50W is typically sufficient and more cost-effective. For standard municipal roads or industrial parks, see our 100W model. Send us your site details and we’ll confirm.
A: Up to 150 lm/W across the Series A/B/C lineup, reducing electricity costs versus traditional lamps.
A: MEAN WELL and PHILIPS, ensuring long-term stability and safety.
A: Yes — 0–10V dimming, DALI, photocell, motion sensor, or LoRa smart systems can be configured on request.
A: 50,000+ hours rated lifespan with a 5-year warranty.
A: Yes — IP65 waterproof and IK08 impact resistance for rain, dust, humidity, and outdoor conditions.
