Addressable Digital Lighting Control

DALI Dimming Control System

A DALI dimming control system enables individual or group-based control of compatible luminaires through a standardized digital interface. It supports precise dimming, programmable scenes and two-way communication for projects requiring more control than conventional group dimming.

MVS supports overseas contractors, consultants and procurement teams with DALI-compatible outdoor luminaires, driver selection, addressing plans and system coordination. The solution can be configured for municipal roads, tunnels, industrial facilities and other projects that require centralized management and flexible operating schedules.

System Components

How a DALI Dimming System Works

DALI uses a dedicated digital control bus to exchange commands and operating information between controllers and compatible lighting equipment. Each luminaire can be addressed individually, assigned to groups or included in programmed lighting scenes.

01

Application Controller

The controller stores schedules, group settings, scenes and dimming commands. It may operate as a standalone device or form part of a larger building or outdoor-lighting management system.

02

DALI Bus Power Supply

The bus power supply provides the operating power required for DALI communication. Its capacity and location must match the selected controller, devices and line design.

03

DALI-Compatible Drivers

Each driver receives digital commands and adjusts the connected LED luminaire. Compatible drivers can report operating status and fault information back to the control system.

04

Gateway and Management Platform

A gateway can connect DALI lighting to a BMS, BACnet network or centralized management platform for monitoring, scheduling and project-wide control.

64 Short addresses available on one DALI line
16 Groups available for coordinated control
16 Programmable scenes supported by control gear
2-Way Commands and operating-status communication
Compatibility requirement: DALI control requires DALI-compatible drivers and controllers designed to the relevant IEC 62386 requirements. Conventional non-DALI drivers cannot receive digital DALI commands without a suitable interface.
Wiring and Address Planning

DALI System Design Considerations

DALI provides flexible wiring and addressing, but the bus power, conductor size, line length and number of connected devices must be confirmed before installation. A documented addressing plan also makes commissioning and future maintenance easier.

Flexible Bus Topology

DALI wiring can use line, tree or star arrangements, including a combination of these layouts. Closed-loop wiring should be avoided, and all branches must remain within the permitted bus-length and voltage-drop limits.

Polarity-Free Control Pair

Standard DALI bus wiring is polarity insensitive, reducing wiring errors during installation. However, the control pair must still be clearly identified and installed according to local electrical requirements.

Address and Group Schedule

Each driver should be recorded with its physical location, short address, group allocation and scene function. This prevents confusion when fixtures are commissioned, replaced or regrouped later.

Bus Power and Voltage Drop

The power supply must support the connected DALI devices without exceeding the system limits. Cable size and distance must also keep the voltage drop within the controller and driver manufacturers’ requirements.

Up to 300 m Typical maximum bus length with suitable conductor sizing
1.5 mm² Common conductor size used for longer DALI bus runs
64 Addresses Maximum short-address capacity on one conventional DALI line
IEC 62386 Main standards family used for DALI-compatible equipment
Engineering note: The 300-metre figure is not a universal guarantee. Final bus length depends on conductor size, bus current, voltage drop and the limits specified by the selected DALI power supply, controller and drivers.
Project Implementation Support

MVS DALI Engineering Services

A reliable DALI project requires compatible luminaires and a documented control plan. MVS supports contractors and project teams from initial product selection through system coordination, commissioning preparation and after-sales service.

01

Wiring and Topology Design

Plan the DALI bus, control-cabinet connections, power-supply locations, cable routes and line divisions according to the project layout.

02

Address and Group Planning

Prepare an addressing schedule that records each luminaire’s location, short address, control group and required scene or operating schedule.

03

Driver Compatibility Review

Confirm that the selected DALI driver matches the luminaire power, output current, voltage range, dimming requirements and control-system specification.

04

DIALux Lighting Design

Provide project-based illuminance, uniformity and energy calculations to coordinate lighting performance with the proposed dimming strategy.

05

System Integration Support

Coordinate DALI gateways and interfaces where the lighting system must connect with BMS, BACnet or a centralized outdoor-lighting platform.

06

Documentation and After-Sales

Support project teams with wiring information, address schedules, product documentation, commissioning records and five-year luminaire warranty service.

Typical Project Deliverables

  • DALI-compatible fixture schedule
  • Driver and controller confirmation
  • Address and group allocation plan
  • Basic wiring and control proposal
Frequently Asked Questions

DALI Dimming FAQ

These answers cover the main protocol, compatibility and system-design questions raised during DALI lighting project planning.

What is the difference between DALI and 0–10V dimming?

DALI is a two-way digital protocol that supports individual addressing, grouping, scenes and operating-status feedback. A 0–10V system uses a one-way analog signal and normally dims all fixtures on the same control line together.

How many luminaires can one DALI line control?

A conventional DALI line supports up to 64 short-addressed control gear devices and 16 groups. The final number of luminaires depends on the system architecture, driver configuration and selected DALI equipment.

Does DALI require a special LED driver?

Yes. Each controlled luminaire requires a DALI-compatible driver or interface capable of receiving digital DALI commands. The driver should comply with the relevant IEC 62386 requirements.

Can DALI integrate with a building management system?

Yes. DALI can connect to BMS or BACnet systems through a compatible gateway. This allows lighting schedules, status information and control functions to be coordinated through a larger management platform.

Can DALI be used for outdoor lighting projects?

Yes. DALI can control compatible street lights, floodlights and tunnel lights. Outdoor drivers, controllers, gateways and connection enclosures must use protection levels suitable for the installation environment.

What information does MVS need for a DALI project?

Provide the lighting layout, fixture quantities, required dimming schedules, control zones, cable distances and management-platform requirements. MVS can then confirm compatible drivers, address capacity and the proposed system structure.

DALI Project Support from MVS

MVS supports DALI-compatible luminaire selection, driver confirmation, address and group planning, basic wiring coordination and DIALux lighting design for municipal, tunnel, industrial and commercial projects.
