The MVS 100W LED street light is our most widely deployed model — sized for standard municipal roads, industrial parks, and parking areas where a 50W fixture would fall short and a 150W+ fixture would be oversized. Every unit is built with certified components and strict quality control for consistent, bidding-grade performance.
Up to 150 lm/W efficiency — bright output with reduced operating costs
Stable illumination with high-quality LEDs — uniform lighting, low decay
Reliable drivers from Mean Well or Inventronics — stable current, extended service life
Optional 0–10V dimming or smart-control interface — supports future smart-lighting upgrades
IP65 aluminum housing — withstands rain, dust, humidity, and temperature swings
Efficient heat-dissipation structure — extends lifespan up to 50,000 hours
Series A covers 100W/120W at a stable 120 lm/W, with beam options 90°/120°/80°×150° — suited for city roads, residential areas, and industrial parks. Best when your project prioritizes standardized specifications and competitive pricing.
Series B covers 100–150W at 140 lm/W, with 80°×150° optics — suited for municipal roads, town roads, and open-area lighting such as parking lots. Best for projects requiring higher efficiency and wider wattage coverage.
Series C covers 100–150W at 145 lm/W with a lightweight 6.2kg housing and 70°×140° precision optics — ideal for internal roads, factory zones, campus areas, and logistics yards where controlled light distribution matters.
A customer in Vietnam selected 1,100 units of MVS 100W LED street lights for a road lighting project. The road was approximately 9 meters wide, with the fixtures installed on 9-meter poles. Pole spacing was adjusted between 27 and 36 meters according to the actual road layout and site conditions.
The customer required each 100W LED street light to operate at full brightness during the first four hours after switching on. After this period, the output automatically reduced to 50% through the preset timer-control program. This provided full lighting during the busier evening hours while reducing unnecessary power consumption later at night.
Each 100W LED street light was configured with Philips LED chips and an Inventronics timer-programmable driver. The 100W output was selected to match the 9-meter road width and 9-meter mounting height, while the programmed dimming schedule helped the customer balance road visibility with long-term energy savings.
| 100W LED Street Light Project Configuration | |
|---|---|
| Product | 100W LED Street Light |
| Quantity | 1,100 units |
| Project Location | Vietnam |
| Application | Timer-controlled road lighting |
| Road Width | 9 meters |
| Pole Height | 9 meters |
| Pole Spacing | 27–36 meters, adjusted to site conditions |
| LED Chips | Philips |
| Driver | Inventronics timer-programmable driver |
| Control Method | Preset timer control |
| First 4 Hours | 100% brightness |
| After 4 Hours | Automatically reduced to 50% brightness |
| Why 100W Was Selected | Suitable output for a 9-meter-wide road with 9-meter mounting poles |
High-efficiency LED output reduces electricity consumption compared with traditional road lamps while maintaining dependable illumination for project roads.
The 100W LED street light is suitable for municipal roads, residential streets, industrial parks and other medium-width road lighting projects.
A robust aluminum housing and weather-resistant finish support reliable operation in rain, heat, dust and demanding outdoor environments.
Practical installation, a 5-year warranty and responsive technical support help contractors complete projects with fewer complications.
| Parameter | MVS-SL100A | MVS-SL100B | MVS-SL100C |
|---|---|---|---|
| Model | MVS-SL100A | MVS-SL100B | MVS-SL100C |
| Power (W) | 100W | 100W | 100W |
| LED Chip | NICHIA / LUMILEDS / CREE | NICHIA / LUMILEDS / CREE | NICHIA / LUMILEDS / CREE |
| Luminous Efficacy (lm/W) | 150 lm/W | 150 lm/W | 150 lm/W |
| CRI | ≥70 | ≥70 | ≥70 |
| Beam Angle | 90° / 120° / 80° / 150° | 80° * 150° | 80° * 150° |
| LED Driver | MEAN WELL / PHILIPS / INVENTRONICS | MEAN WELL / PHILIPS / INVENTRONICS | MEAN WELL / PHILIPS / INVENTRONICS |
| Input Voltage (V) | 85–277V | 85–277V | 85–277V |
| LED Quantity (pcs) | 128 pcs | 256 pcs | 192 pcs |
| Net Weight (kg) | 8.6 kg | 6 kg | 6.2 kg |
TÜV-certified CE and CB. ISO 9001 quality management. EMC and LVD compliant drivers.
Choose our 100W LED streetlights, featuring internationally renowned chips and boasting a luminous efficacy of up to 150 lm/W. Backed by a five years warranty, these lights are suitable for a variety of outdoor locations, including municipal roads, bridges, ports, and stadiums. Contact us today to discuss your customized streetlighting solution.
Q: What is the warranty period for the 100W streetlight?
A: 5-year warranty, with free replacement or repair for quality-related malfunctions.
Q: What locations are 100W streetlights suitable for?
A: Urban roads, rural roads, tunnels, industrial parks, campuses, and parking lots — suitable for both local projects and international exports.
Q: Can the beam angle or power be customized?
A: Yes — multiple beam angles (90°/120°/80°×150°) and OEM/ODM customization are available.
Q: What driver options are available?
A: MEAN WELL, PHILIPS, and INVENTRONICS.
Q: Which countries can the 100W streetlight be exported to?
A: CE, CB, ISO9001 certified for export to Europe, the Middle East, Southeast Asia, and 50+ countries.
Q: What is the lifetime of the 100W streetlight?
A: 50,000+ hours of rated operation.
Q: Should I choose 100W, or would 50W/150W fit better?
A: 100W suits standard municipal roads and industrial parks. If your project has lower mounting height and lighter traffic, see our 50W model; for main roads or a metal-halide replacement upgrade, see our 150W model.
